Descrizione

LiFePO4 Battery with Enhanced Output: Utilizing the same LiFePO4 (Lithium Iron Phosphate) battery technology as the PowerMax 3600, the PowerMax 6000 offers a capacity of 3,600Wh and a significant increase in total output power to 6,000W, with a surge power capability of 9,000W.

Enhanced Charging Capabilities: Improved charging capabilities include an increased AC input power to 2200W, a solar input capacity raised to 2400W, and a doubled car input to 240W. These enhancements lead to faster charging times: 1.96 hours via AC, 1.5 hours via solar in prime conditions, and a maximum combined AC and solar charging time of 1.44 hours.

Versatile Output Ports: The PowerMax 6000 supports a total output power of 6,000W through four AC outlets, along with 2x PD 100W USB Type-C, 3x PD 18W USB Type-A, 1x PD 12W USB Type-A, and a 120W cigarette lighter socket. It also features 1x 12V/25A (Anderson 378W outlet) and 2x 12V/3A DC5521 (5.5mm outlet) DC outputs.

Improved Mobility and Management System: Equipped with industrial wheels and an extendable handle for easy mobility, the PowerMax 6000 includes a 5-level LED lamp, an upgrade from the basic LED light on the PowerMax 3600. Both models are managed by the T1 chip, which monitors load, voltage, charging, and temperature for optimal performance and safety.

Compact and Robust Design: The PowerMax 6000 retains the same compact dimensions as the PowerMax 3600 (590 x 350 x 441 mm), but with a slightly heavier weight of 101.41 lbs (46 kg). Both models feature splash and dust-proof protection, making them ideal for outdoor use and rugged environments.

Specification:

Discharging Temperature: -20℃ to 55℃ or (-4°F to 131°F)

Battery Type: LiFePO4 (Lithium Iron Phosphate)

Battery Capacity: 3,600Wh

battery packs：3600WH

Lifecycle: 3500+ Cycles to 80% of Original Capacity

Shelf-Life: Recharge to above 50% Every 3 Months

Management System: T1 Chip integrated with BMS

Monitoring: Load / Voltage Monitoring,Charging Monitoring,Temperature monitoring

AC Input: up 2200W

Solar Input: up 2400W Max.

Car Input: up 240W from Cigarette Lighter Port

AC Charging Time: 1.96 hours

Solar Charging Time: 1.5 hours (Prime sunshine)

AC + Solar Charging Time: Max 3000W Supported; 1.44 hours

Car Charging Time: 15 hours

Total Output Power: 6,000W

Inverter Type: Pure Sine Wave

Surge Power: 9,000W

AC Outlets: 4 X AC Outlets (Total 6000W)

USB Ports:

2x PD 100W – USB Type-C

3x PD 18W – USB Type-A

1x PD 12W – USB Type-A

Cigarette Lighter Sockets: 1 x Cigarette Lighter – 120W (Car Outlet)

LED light: 5 level LED lamp

DC Outlets:

1 x 12V/25A (Anderson 378W Outlet)

2 x 12V/3A DC5521 (5.5mm Outlet)

Product Weight: 46kg

Package Weight: 51kg

Product Size(L x W x H): 59x35x44.1cm

Package Size(L x W x H): 66×40.5×52.5cm

Package List:

PowerMax6000+BP3600 T200 US:

1 x Oscal PowerMax 6000 US

1x Battery pack BP3600

1 x AC Charge Cable

1 x Solar Charging Cable

1 x Car charging cable

1 x User Manual

Solar panel*1

MC4 charging cable*1

PowerMax6000+BP3600 EU:

1 x Oscal PowerMax 6000 EU

1x Battery pack BP3600

1 x AC Charge Cable

1 x Solar Charging Cable

1 x Car charging cable

1 x User Manual

Solar panel*1

MC4 charging cable*1

200W Solar Panel:

With a maximum output of 200W (Pm), the 200W solar panel is capable of rapidly charging a multitude of devices. The 200W solar panel offers dependable power support during outdoor activities or as a backup power source for the home.

High Conversion Efficiency:

The 200W solar panel, featuring ETFE film and monocrystalline silicon, achieves up to 23.4% conversion efficiency. Its design enhances light absorption and efficiency, providing reliable electricity even in low light. This green energy solution eliminates the need for fuel-based generators by harnessing solar power.

The product’s versatile design allows for a variety of applications.

The 200W solar panel features four foldable panels. The unfolded size is (58 x 172 x 3 cm/22.8*67.7*11.8 inches), and the lightweight design of 6.1kg/13.5lbs makes it easy to carry when moving. The product is suitable for a wide range of applications, including camping, hiking, disaster prevention, and more.

A stable power supply is essential for optimal performance.

The 200W solar panel provides an output voltage of up to 18V (max) and an output current of up to 11.1A (max), ensuring a reliable power supply. Furthermore, the open circuit voltage (Voc) is 21.6V and the short circuit current (Isc) is 13.3A, which ensures stable power supply even in the event of a damaged solar panel.

The 200W solar panel is designed to operate in a wide ambient temperature range of -10℃ to 65℃.

Furthermore, the optimal operating temperature is +25°C, which allows for efficient charging even at high temperatures. Furthermore, the product is backed by a five-year warranty, providing customers with added confidence in its performance.

Solar panels that can be connected in series or parallel.

The solar charger can be connected in series (increasing voltage) or in parallel (increasing current) using multiple panels (up to three panels). Should you require assistance with the connection process, please do not hesitate to contact us
