Model
|
T15K
|
T30K
|
|
|
Capacity(W)
|
15000W
|
30000W
|
|
|
DC voltage(V)
|
192V(240V optional)
|
240V(360V optional)
|
|
|
Input voltage(V)
|
380V± 20%
|
||
|
Input frequency
|
45-65HZ
|
||
|
Output voltage
|
Four steps AVR, 380V/415V/440V for optional
|
||
|
Output wave form
|
Pure sine wave
|
||
|
THD
|
≤ 3%
|
||
|
Low-voltage protection(V)
|
78/216
|
216/322
|
|
|
Over voltage protection(V)
|
120/272
|
272/480
|
|
|
Recharge current
|
30-40A
|
30-40A
|
|
|
Unit size(mm)
|
820*1170*1670
|
785*580*1790
|
|
|
Transfer efficiency
|
95%
|
||
|
Protections
|
Protection against short-circuit, over load, high-voltage, reverse polarity protection and low-voltage protection
|
||
|
Over load
|
120% of the rate capacity
|
||
|
Short circuit
|
300% of the rate capacity
|
||
Three phase inverter / solar, wind system off grid inverter Feature:
1.with AC reacto(protect against city power current shock)
2.Double Protection(Two fuses,including the city power security and battery power security)
3.Thyristorcharging (40-50a)
4.IGBT converter(High 95% transfer efficiency)
5.AC filter capacitor.
6.IGBT brand(Mitsubishi)
7.SCR brand(
8.All inverter with IOT,get life-long maintenance.
9.we have live stream every week,welcome to test the working performance of the inverter online and experience the use effect
TANFON 40kw inverter off grid power solar system installation in Colombia
30KW-200KW if for commercial building use，
to provide 24-hour uninterrupted power supply, so that the shopping mall can maintain sufficient power.
